This CP series current transformer has 12 models totally. The product structure is compact, the size is smaller than other series, the flip-open cover can protect the secondary terminal well. It is equipped with necessary accessories, and it can be DIN rail mounting.

Feature

★ Three mounting ways: baseboard, DIN rail, busbar

★ Built-in flip-open cover

★ Compact design

★ Rated primary current from 5A to 3000A

Specification

Rated frequency: 50/60Hz

Rated withstand voltage: 3kV AC (1min)

Rated thermal current (Ith): 60In

Dynamic stable current: 2.5Ith

Rated voltage (Um): 0.72kV AC

Continuous overload (Id): 1.2In

Operating temperature:  -10℃~50℃

Flame retardant rating of housing:  VO

Safety factor: FS 5

Secondary current: 5A/1A

Standard

IEC60044-1  GB1208-2006
