CP74/40 Series Current Transformers

Short Description:

This CP series current transformer has 12 models totally The product .structure is compact the size is smaller than other series the flip open cover can protect the secondary terminal well It is equipped with necessary .

Frequency Range: 50Hz-60Hz
Rated Power-Frequency Withstand Voltage (rms): 3kV AC (1 min)
Highest voltage for equipment: 0.72kV AC
Rated short-time thermal current(lth): 60ln
Rated dynamic current(ldyn): 2.5lth
Continuous overload: 1.2ln
Operating temperature: -20°C to 75°C
Rated security coefficient: 2.5lth
Standard: IEC 61869-2

CONTACT NOW down load to pdf

Details

Tags

Model	Primary (A)	Secondry	Rated Burden(VA)
			Class 1.0			Class 0.5
			2.5	5	10	2.5	5	10
CP74/40	150	1A、5A	A1	-	-	-	-	-
	200	1A、5A	B1	B2	-	B4	B5	-
	300	1A、5A	C1	C2	-	C4	C5	-
	400	1A、5A	D1	D2	-	D4	D5	-
	500	1A、5A	E1	E2	-	E4	E5	-
	600	1A、5A	F1	F2	F3	F4	F5	F6
	700	1A、5A	G1	G2	G3	G4	G5	G6
	800	1A、5A	H1	H2	H3	H4	H5	H6
